Shinho X-97 Optical Fiber Splicing Machine
(0
reviews)
Estimate Shipping Time:
4 Days
Inhouse product
Price
৳0.00
/Pcs
Share
Top Selling Products
Full Specification
| Item | Splicer Machine |
|---|---|
| Model | ✅ Shinho X-97 |
| Splicing Time | 6~12 second |
| Splicing Program | 40 group |
| Splice Loss | G651: 0.01dB; G652: 0.02dB; G653: 0.04dB; G655: 0.04dB; G657: 0.02dB |
| Fiber Cleave Length | 10-16mm |
| Fiber Diameter | 80 -150μm |
| Fiber Magnification | 320X (X or Y view), 160X (X and Y view) |
| Applicable Fiber | G651 / G652 / G653 / G655 / G657 etc. |
| Heating Time | 20~26 seconds for 40mm and 60mm shrinkable sleeves |
| Tension Test | 1.8~2.2n |
| Return Loss | ＞60dB |
| Operate Mode | Automatic / Manual |
| Result Storage | 4000 |
| Display | 4.3-inch color LCD monitor |
| Battery | 5200mAh Li-battery, typical 250 cycles splicing and heating |
| Electrodes Life Time | More than 4000 ARC discharges |
| Interface | GUI menu interface, easy for operation |
| Power | input: AC 100-240V(50/50HZ), output: 11-13.5V |
| Others | 2 CMOS camera |
| Weight | 1.9 Kg weight included battery |
| Dimension | 149 x 120 x 127mm |
